F58R38減速機詳細信息
F58R38減速機
F58R38減速機電機功率：F58R38Y0.12KW減速機,F58R38Y0.18KW減速機,F58R38Y0.25KW減速機,F58R38Y0.37KW減速機（可配變頻電機，剎車電機，防爆電機，伺服電機，交流電機，直流電機，三相電機，單相電機）。
F58R38減速機配0.12KW電機參數
| 型號 | 減速比 | 功率 | 轉數 | 扭矩 | 重量 | 力矩 | 安全系數 |
| F58R38-Y0.12KW | 851 | 0.12KW | 1.60r/min | 610N.m | 48kg | 9100N | 1.00 |
| F58R38-Y0.12KW | 738 | 0.12KW | 1.90r/min | 520N.m | 48kg | 9750N | 1.15 |
| F58R38-Y0.12KW | 646 | 0.12KW | 2.10r/min | 455N.m | 48kg | 10200N | 1.30 |
| F58R38-Y0.12KW | 558 | 0.12KW | 2.50r/min | 385N.m | 48kg | 10600N | 1.55 |
| F58R38-Y0.12KW | 506 | 0.12KW | 2.70r/min | 345N.m | 48kg | 10900N | 1.75 |
| F58R38-Y0.12KW | 452 | 0.12KW | 3.00r/min | 295N.m | 48kg | 11100N | 2.00 |
| F58R38-Y0.12KW | 426 | 0.12KW | 3.20r/min | 310N.m | 48kg | 11100N | 1.95 |
| F58R38-Y0.12KW | 382 | 0.12KW | 3.60r/min | 270N.m | 48kg | 11300N | 2.20 |
| F58R38-Y0.12KW | 330 | 0.12KW | 4.20r/min | 230N.m | 48kg | 11500N | 2.60 |
| F58R38-Y0.12KW | 298 | 0.12KW | 4.60r/min | 210N.m | 48kg | 11500N | 2.80 |
| F58R38-Y0.12KW | 262 | 0.12KW | 5.30r/min | 185N.m | 48kg | 11500N | 3.20 |
F58R38減速機配0.18KW電機參數
| 型號 | 減速比 | 功率 | 轉數 | 扭矩 | 重量 | 力矩 | 安全系數 |
| F58R38-Y0.18KW | 558 | 0.18KW | 2.40r/min | 635N.m | 48.5kg | 7570N | 0.95 |
| F58R38-Y0.18KW | 506 | 0.18KW | 2.60r/min | 570N.m | 48.5kg | 9420N | 1.05 |
| F58R38-Y0.18KW | 452 | 0.18KW | 2.90r/min | 495N.m | 48.5kg | 9930N | 1.20 |
| F58R38-Y0.18KW | 386 | 0.18KW | 3.40r/min | 425N.m | 48.5kg | 10400N | 1.40 |
| F58R38-Y0.18KW | 338 | 0.18KW | 3.90r/min | 370N.m | 48.5kg | 10700N | 1.60 |
| F58R38-Y0.18KW | 426 | 0.18KW | 3.10r/min | 500N.m | 48.5kg | 9910N | 1.20 |
| F58R38-Y0.18KW | 382 | 0.18KW | 3.50r/min | 445N.m | 48.5kg | 10300N | 1.35 |
| F58R38-Y0.18KW | 330 | 0.18KW | 4.00r/min | 380N.m | 48.5kg | 10700N | 1.55 |
| F58R38-Y0.18KW | 298 | 0.18KW | 4.40r/min | 340N.m | 48.5kg | 10900N | 1.75 |
| F58R38-Y0.18KW | 262 | 0.18KW | 5.00r/min | 300N.m | 48.5kg | 11100N | 2.00 |
| F58R38-Y0.18KW | 226 | 0.18KW | 5.80r/min | 255N.m | 48.5kg | 11400N | 2.30 |
| F58R38-Y0.18KW | 200 | 0.18KW | 6.60r/min | 220N.m | 48.5kg | 11500N | 2.70 |
F58R38減速機配0.25KW電機參數
| 型號 | 減速比 | 功率 | 轉數 | 扭矩 | 重量 | 力矩 | 安全系數 |
| F58R38-Y0.25KW | 386 | 0.25KW | 3.40r/min | 620N.m | 52.5kg | 8830N | 0.95 |
| F58R38-Y0.25KW | 338 | 0.25KW | 3.80r/min | 540N.m | 52.5kg | 9640N | 1.10 |
| F58R38-Y0.25KW | 255 | 0.25KW | 5.10r/min | 405N.m | 52.5kg | 10500N | 1.45 |
| F58R38-Y0.25KW | 382 | 0.25KW | 3.40r/min | 635N.m | 52.5kg | 7390N | 0.95 |
| F58R38-Y0.25KW | 330 | 0.25KW | 3.90r/min | 550N.m | 52.5kg | 9570N | 1.10 |
| F58R38-Y0.25KW | 298 | 0.25KW | 4.40r/min | 495N.m | 52.5kg | 9950N | 1.20 |
| F58R38-Y0.25KW | 262 | 0.25KW | 5.00r/min | 435N.m | 52.5kg | 10300N | 1.35 |
| F58R38-Y0.25KW | 226 | 0.25KW | 5.80r/min | 370N.m | 52.5kg | 10700N | 1.60 |
| F58R38-Y0.25KW | 200 | 0.25KW | 6.50r/min | 320N.m | 52.5kg | 11000N | 1.85 |
| F58R38-Y0.25KW | 170 | 0.25KW | 7.60r/min | 275N.m | 52.5kg | 11300N | 2.20 |
F58R38減速機配0.37KW電機參數
| 型號 | 減速比 | 功率 | 轉數 | 扭矩 | 重量 | 力矩 | 安全系數 |
| F58R38-Y0.37KW | 255 | 0.37KW | 5.40r/min | 580N.m | 53kg | 9330N | 1.05 |
| F58R38-Y0.37KW | 201 | 0.37KW | 6.90r/min | 455N.m | 53kg | 10200N | 1.30 |
| F58R38-Y0.37KW | 181 | 0.37KW | 7.60r/min | 410N.m | 53kg | 10500N | 1.45 |
| F58R38-Y0.37KW | 262 | 0.37KW | 5.30r/min | 615N.m | 53kg | 9070N | 0.95 |
| F58R38-Y0.37KW | 226 | 0.37KW | 6.10r/min | 525N.m | 53kg | 9740N | 1.15 |
| F58R38-Y0.37KW | 200 | 0.37KW | 6.90r/min | 460N.m | 53kg | 10200N | 1.30 |
| F58R38-Y0.37KW | 170 | 0.37KW | 8.10r/min | 390N.m | 53kg | 10600N | 1.50 |
| F58R38-Y0.37KW | 152 | 0.37KW | 9.00r/min | 345N.m | 53kg | 10900N | 1.70 |
| F58R38-Y0.37KW | 134 | 0.37KW | 10.0r/min | 305N.m | 53kg | 11100N | 1.95 |
F58R38減速器減速比：134比齒輪減速馬達,152比減速器,170比減速器,181比減速器,200比減速器,201比減速器,226比減速器,255比減速器,262比減速器,298比減速器,330比減速器,338比減速器,382比減速器,386比減速器,426比減速器,452比減速器,506比減速器,558比減速器,646比減速器,738比減速器,851比減速器。
F58R38減速機電機安裝尺寸：輸出軸Φ35+鍵3（可定做），高315*寬200*長400（帶輸出軸）
F58R38減速電機輸出轉數：1.6轉減速電機,1.9轉減速電機,2.1轉平行軸斜齒輪減速機,2.4轉減速電機,2.5轉減速電機,2.6轉減速電機,2.7轉減速電機,2.9轉減速電機,3轉減速電機,3.1轉減速電機,3.2轉減速電機,3.4轉減速電機,3.5轉減速電機,3.6轉減速電機,3.8轉減速電機,3.9轉減速電機,4轉減速電機,4.2轉減速電機,4.4轉減速電機,4.6轉減速電機,5轉減速電機,5.1轉減速電機,5.3轉減速電機,5.4轉減速電機,5.8轉減速電機,6.1轉減速電機,6.5轉減速電機,6.6轉減速電機,6.9轉減速電機,7.6轉減速電機,8.1轉減速電機,9轉減速電機,10轉減速電機。
F58R38減速箱電機輸出扭矩：185N.m減速箱,210N.m減速箱,220N.m減速箱,230N.m減速箱,255N.m減速箱,270N.m減速箱,275N.m減速箱,295N.m減速箱,300N.m減速箱,305N.m減速箱,310N.m減速箱,320N.m減速箱,340N.m減速箱,345N.m減速箱,370N.m減速箱,380N.m減速箱,385N.m減速箱,390N.m減速箱,405N.m減速箱,410N.m減速箱,425N.m減速箱,435N.m減速箱,445N.m減速箱,455N.m減速箱,460N.m減速箱,495N.m減速箱,500N.m減速箱,520N.m減速箱,525N.m減速箱,540N.m減速箱,550N.m減速箱,570N.m減速箱,580N.m減速箱,610N.m減速箱,615N.m減速箱,620N.m減速箱,635N.m減速箱。
F58R38減速機電機各種輸出實物圖：
F58R38減速馬達型號：
FHZ57R37DM63L4,FHZ57R37DM63M4,FHZ57R37DM63MS4,FHZ57R37DM63S4,FHZ57R37DM71D4,FHZ57R37DM71M4,FHZ57R37DM71MS4,FHZ57R37DM71S4,FHZ57R37DR63L4,FHZ57R37DR63M4,FHZ57R37DR63MS4,FHZ57R37DR63S4,FHZ57R37DR71D4,FHZ57R37DR71M4,FHZ57R37DR71MS4,FHZ57R37DR71S4,FHZ57R37DRE63L4,FHZ57R37DRE63M4,FHZ57R37DRE63MS4,FHZ57R37DRE63S4,FHZ57R37DRE71D4,FHZ57R37DRE71M4,FHZ57R37DRE71MS4,FHZ57R37DRE71S4,FHZ57R37DRN63L4,FHZ57R37DRN63M4,FHZ57R37DRN63MS4,FHZ57R37DRN63S4,FHZ57R37DRN71D4,FHZ57R37DRN71M4,FHZ57R37DRN71MS4,FHZ57R37DRN71S4,FHZ57R37DRS63L4,FHZ57R37DRS63M4,FHZ57R37DRS63MS4,FHZ57R37DRS63S4,FHZ57R37DRS71D4,FHZ57R37DRS71M4,FHZ57R37DRS71MS4,FHZ57R37DRS71S4,FHZ57R37DT63L4,FHZ57R37DT63M4,FHZ57R37DT63MS4,FHZ57R37DT63S4,FHZ57R37DT71D4,FHZ57R37DT71M4,FHZ57R37DT71MS4,FHZ57R37DT71S4,FHZ57R37DV63L4,FHZ57R37DV63M4,FHZ57R37DV63MS4,FHZ57R37DV63S4,FHZ57R37DV71D4,FHZ57R37DV71M4,FHZ57R37DV71MS4,FHZ57R37DV71S4,FHZ57R37DVE63L4,FHZ57R37DVE63M4,FHZ57R37DVE63MS4,FHZ57R37DVE63S4,FHZ57R37DVE71D4,FHZ57R37DVE71M4,FHZ57R37DVE71MS4,FHZ57R37DVE71S4,FHZ57RF37-Y0.12KW,FHZ57RF37-Y0.18KW,FHZ57RF37-Y0.25KW,FHZ57RF37-Y0.37KW,FHZ57RF37-YEJ0.12KW,FHZ57RF37-YEJ0.18KW,FHZ57RF37-YEJ0.25KW,FHZ57RF37-YEJ0.37KW,FHZ57RF37-YVP0.12KW,FHZ57RF37-YVP0.18KW,FHZ57RF37-YVP0.25KW,FHZ57RF37-YVP0.37KW,FHZ57RF37-YVPEJ0.12KW,FHZ57RF37-YVPEJ0.18KW,FHZ57RF37-YVPEJ0.25KW,FHZ57RF37-YVPEJ0.37KW,FHZ57RF37-Y63M4,FHZ57RF37-Y71M4,FHZ57RF37-YEJ63M4,FHZ57RF37-YEJ71M4,FHZ57RF37-YVP63M4,FHZ57RF37-YVP71M4,FHZ57RF37-YVPEJ63M4,FHZ57RF37-YVPEJ71M4,FVZ57R37DM63L4,FVZ57R37DM63M4,FVZ57R37DM63MS4,FVZ57R37DM63S4,FVZ57R37DM71D4,FVZ57R37DM71M4,FVZ57R37DM71MS4,FVZ57R37DM71S4,FVZ57R37DR63L4,FVZ57R37DR63M4,FVZ57R37DR63MS4,FVZ57R37DR63S4,FVZ57R37DR71D4,FVZ57R37DR71M4,FVZ57R37DR71MS4,FVZ57R37DR71S4,FVZ57R37DRE63L4,FVZ57R37DRE63M4,FVZ57R37DRE63MS4,FVZ57R37DRE63S4,FVZ57R37DRE71D4,FVZ57R37DRE71M4,FVZ57R37DRE71MS4,FVZ57R37DRE71S4,FVZ57R37DRN63L4,FVZ57R37DRN63M4,FVZ57R37DRN63MS4,FVZ57R37DRN63S4,FVZ57R37DRN71D4,FVZ57R37DRN71M4,FVZ57R37DRN71MS4,FVZ57R37DRN71S4,FVZ57R37DRS63L4,FVZ57R37DRS63M4,FVZ57R37DRS63MS4,FVZ57R37DRS63S4,FVZ57R37DRS71D4,FVZ57R37DRS71M4,FVZ57R37DRS71MS4,FVZ57R37DRS71S4,FVZ57R37DT63L4,FVZ57R37DT63M4,FVZ57R37DT63MS4,FVZ57R37DT63S4,FVZ57R37DT71D4,FVZ57R37DT71M4,FVZ57R37DT71MS4,FVZ57R37DT71S4,FVZ57R37DV63L4,FVZ57R37DV63M4,FVZ57R37DV63MS4,FVZ57R37DV63S4,FVZ57R37DV71D4,FVZ57R37DV71M4,FVZ57R37DV71MS4,FVZ57R37DV71S4,FVZ57R37DVE63L4,FVZ57R37DVE63M4,FVZ57R37DVE63MS4,FVZ57R37DVE63S4,FVZ57R37DVE71D4,FVZ57R37DVE71M4,FVZ57R37DVE71MS4,FVZ57R37DVE71S4,FVZ57RF37-Y0.12KW,FVZ57RF37-Y0.18KW,FVZ57RF37-Y0.25KW,FVZ57RF37-Y0.37KW,FVZ57RF37-YEJ0.12KW,FVZ57RF37-YEJ0.18KW,FVZ57RF37-YEJ0.25KW,FVZ57RF37-YEJ0.37KW,FVZ57RF37-YVP0.12KW,FVZ57RF37-YVP0.18KW,FVZ57RF37-YVP0.25KW,FVZ57RF37-YVP0.37KW,FVZ57RF37-YVPEJ0.12KW,FVZ57RF37-YVPEJ0.18KW,FVZ57RF37-YVPEJ0.25KW,FVZ57RF37-YVPEJ0.37KW,FVZ57RF37-Y63M4,FVZ57RF37-Y71M4,FVZ57RF37-YEJ63M4,FVZ57RF37-YEJ71M4,FVZ57RF37-YVP63M4,FVZ57RF37-YVP71M4,FVZ57RF37-YVPEJ63M4,FVZ57RF37-YVPEJ71M4,FAZ57R37DM63L4,FAZ57R37DM63M4,FAZ57R37DM63MS4,FAZ57R37DM63S4,FAZ57R37DM71D4,FAZ57R37DM71M4,FAZ57R37DM71MS4,FAZ57R37DM71S4,FAZ57R37DR63L4,FAZ57R37DR63M4,FAZ57R37DR63MS4,FAZ57R37DR63S4,FAZ57R37DR71D4,FAZ57R37DR71M4,FAZ57R37DR71MS4,FAZ57R37DR71S4,FAZ57R37DRE63L4,FAZ57R37DRE63M4,FAZ57R37DRE63MS4,FAZ57R37DRE63S4,FAZ57R37DRE71D4,FAZ57R37DRE71M4,FAZ57R37DRE71MS4,FAZ57R37DRE71S4,FAZ57R37DRN63L4,FAZ57R37DRN63M4,FAZ57R37DRN63MS4,FAZ57R37DRN63S4,FAZ57R37DRN71D4,FAZ57R37DRN71M4,FAZ57R37DRN71MS4,FAZ57R37DRN71S4,FAZ57R37DRS63L4,FAZ57R37DRS63M4,FAZ57R37DRS63MS4,FAZ57R37DRS63S4,FAZ57R37DRS71D4,FAZ57R37DRS71M4,FAZ57R37DRS71MS4,FAZ57R37DRS71S4,FAZ57R37DT63L4,FAZ57R37DT63M4,FAZ57R37DT63MS4,FAZ57R37DT63S4,FAZ57R37DT71D4,FAZ57R37DT71M4,FAZ57R37DT71MS4,FAZ57R37DT71S4,FAZ57R37DV63L4,FAZ57R37DV63M4,FAZ57R37DV63MS4,FAZ57R37DV63S4,FAZ57R37DV71D4,FAZ57R37DV71M4,FAZ57R37DV71MS4,FAZ57R37DV71S4,FAZ57R37DVE63L4,FAZ57R37DVE63M4,FAZ57R37DVE63MS4,FAZ57R37DVE63S4,FAZ57R37DVE71D4,FAZ57R37DVE71M4,FAZ57R37DVE71MS4,FAZ57R37DVE71S4,FAZ57RF37-Y0.12KW,FAZ57RF37-Y0.18KW,FAZ57RF37-Y0.25KW,FAZ57RF37-Y0.37KW,FAZ57RF37-YEJ0.12KW,FAZ57RF37-YEJ0.18KW,FAZ57RF37-YEJ0.25KW,FAZ57RF37-YEJ0.37KW,FAZ57RF37-YVP0.12KW,FAZ57RF37-YVP0.18KW,FAZ57RF37-YVP0.25KW,FAZ57RF37-YVP0.37KW,FAZ57RF37-YVPEJ0.12KW,FAZ57RF37-YVPEJ0.18KW,FAZ57RF37-YVPEJ0.25KW,FAZ57RF37-YVPEJ0.37KW,FAZ57RF37-Y63M4,FAZ57RF37-Y71M4,FAZ57RF37-YEJ63M4,FAZ57RF37-YEJ71M4,FAZ57RF37-YVP63M4,FAZ57RF37-YVP71M4,FAZ57RF37-YVPEJ63M4,FAZ57RF37-YVPEJ71M4。
F58R38減速電機生產廠家展示：看廠請聯系微信13827261050，獲取位置，需提前一天預約http://www.272323.com/product/list-fxiliejiansuji-cn.html
推薦型號：F58減速機
關鍵詞:GF型配減速器的電機一體式_F系列減速機_F系列減速器_減速機配電機_配減速器的電機_配減速機的電機_電機配減速機_GF系列減速機_F型減速機_F型平行軸斜齒輪減速機_減速器配電機
F系列齒輪減速馬達型號：F28減速機,F38減速機,F48減速機,F68減速機,F78減速機,F88減速機,F98減速機,F108減速機,F128減速機,F158減速機
F系列電動機減速機可配變頻電機，剎車電機，防爆電機，伺服電機，交流電機，直流電機，三相電機，單相電機 0.12KW-132KW之間
如需工程師幫選型，請加微信13827261050，留言告知工程師參數要求
標簽: FHZ57R37 FVZ57R37 FAZ57R37 F57RF37
